Design and Implementation of Planar Fourtear Microstrip Antenna for WLAN and WiMAX Applications

  Ken Paramayudha (1*), Yuyu Wahyu (2), Aprilia Pustpita Sari (3), Heroe Wijanto (4)

(1) Telkom University - Indonesia
(2) Indonesian Institutes of Sciences - Indonesia
(3) Telkom University
(4) Telkom University
(*) Corresponding Author

Received: November 21, 2016; Revised: November 28, 2016
Accepted: December 05, 2016; Published: December 15, 2016


How to cite (IEEE): K. Paramayudha, Y. Wahyu, A. Sari,  and H. Wijanto, "Design and Implementation of Planar Fourtear Microstrip Antenna for WLAN and WiMAX Applications," Jurnal Elektronika dan Telekomunikasi, vol. 16, no. 1, pp. 20-24, Dec. 2016. doi: 10.14203/jet.v16.20-24

Abstract

In this paper, the microstrip planar fourtear antenna that operate at frequency range 2300 – 2500 MHz was investigated, Some applications suitable to operate in this frequency are WiMAX at 2.3 and 2.5 GHz and WLAN at 2.4 GHz. Simulations performed with the aid of Finite Element Emthod (FEM) based software which can calculte and comply the appropriate design to be able to operate at the desired working frequency. The analyzed parameters include : SWR, impedance, return loss, radiation patterns, gain, and polarization. From the measurement, bandwidth obtained is equal to 7.69% in the frequency range of 2318,250-2500 MHz in VSWR < 2. Radiation pattern measurement was unidirectional and the polarization was elliptical.

  http://dx.doi.org/10.14203/jet.v16.20-24

Keywords


fourtear; VSWR; unidirectional; elliptical

Full Text:

  PDF

References


C. Puente-baliarda and J. Romeu, “On the behavior of the sierpinski multiband fractal antenna,” IEEE Trans. on Antennas and propagation, vol. 46, no. 4, pp. 517–524, 1998.

C. P. Baliarda, J. Romeu, and A. Cardama, “The koch monopole : a small fractal antenna,” IEEE Trans. on Antennas and propagation, vol. 48, no. 11, pp. 1773–1781, 2000.

S. Dhar, S. Member, R. Ghatak, B. Gupta, D. R. Poddar, and S. Member, “A wideband minkowski fractal dielectric resonator antenna,” EEE Trans. on Antennas and propagation, vol. 61, no. 6, pp. 2895-2903, 2013.

J. Tao, Q. Feng, and D. Tian, “Compact coplanar waveguide-fed ultra-wideband MIMO antenna with half slot structure,” in Progress in Electromagnetic Research Symposium (PIERS), pp. 1236-1240, 2016.

Y. Wang, F. Zhu, and S. Ga, “Planar dual-polarized slot antenna for UWB MIMO applications,” in Progress in Electromagnetic Research Symposium (PIERS), pp. 2045–2047, 2016.

L. Han, C. Wang, X. Chen, and W. Zhang, “Compact frequency reconfigurable slot antenna for wireless applications,” vol. 1225, pp. 3–6, 2016.

F. Gozasht, A. Boddupalli, S. S. H. Ling, and A. S. Mohan, “Singly-fed shaped planar inverted-F antenna for circular polarization,” in Proc. of IEEE Microwave Symposium (AMS), pp. 33-34, 2016.

R. J. Kaur, D. Khosla, and P. Sahni, “Design of a compact planar inverted-F antenna for WiMAX and WLAN USB dongle applications,” in Proc. of IEEE Conference on Signal Processing and Integrated Networks (SPIN), pp. 562-565, 2016.

L. Harle, C. Oakley, and J. Papapolymerou, “3D-printed dual band planar inverted F antenna,” in Proc of IEEE International Symposium on Antennas and Propagation (APSURSI), pp. 817–818, 2016.

W. Davistt, “A generalized crossed dipole antenna, the fourtear antenna,” in Proc. of IEEE Antennas and Propagation Society International Symposium, pp. 2915-2918, 2004.

C. A. Balanis, Antenna theory : analysis and design, New York : Harper & Row Publisher, 1982.
